Description
The Stovax Studio Air 1 Inset offers a perfect balance of contemporary design and efficient heating, delivering a stunning wide flame view within a compact inset format.
With a nominal 5kW heat output, this model is ideal for standard living spaces, combining advanced combustion technology with a minimalist, hole-in-the-wall aesthetic.
Key Features
- Fuel type: Wood burning
- Heat output: 5.0kW (range 1.7–7kW)
- Efficiency: 79.6%
- Energy rating: A
- Ecodesign compliant
- DEFRA exempt – suitable for smoke control areas
- Cleanburn technology for reduced emissions
- Powerful Airwash system for a clear flame view
- Single air control for easy operation
- Boost mode for rapid ignition
- High-density firebrick lining & dual-layer firebox
- Cast iron base for durability
- Optional external air supply (room sealed)
- Optional warm air ducting kit (up to 2 rooms)
- Reversible door (optional kit)
- Maximum log length: 300mm
- Flue outlet: 6” (152mm)
Fire Dimensions (mm)
| Width | Height | Depth |
|---|---|---|
| 783 | 452 | 348 |
Frame Dimensions (mm)
| Width | Height | Depth | |
| Edge+ | 817 | 488 | 3.5 |
| Profil (3-Sided) | 879 | 500 | 38 |
| Profil (4-Sided) | 879 | 550 | 38 |
Design & Performance
The Studio Air 1 delivers a clean, contemporary inset look with a low fuel bed, allowing for a wide and uninterrupted view of the flames. Its advanced combustion system uses precision airflow and tertiary air jets to burn fuel efficiently while minimising emissions.
The powerful Airwash system keeps the glass clear, ensuring the fire remains a captivating focal point at all times.
Built for Modern Living
Designed with flexibility in mind, the Studio Air 1 features an integrated external air connection, allowing it to be installed as a room-sealed appliance - ideal for modern, airtight homes.
Ease of Use
A single air control provides simple and responsive adjustment of the flame, while the boost mode makes lighting quick and effortless - even from a cold start.
Frame & Finish Options
- Edge (frameless) – minimalist hole-in-the-wall design
- Edge+ – slim frame for a clean finish
- Profil (3 or 4-sided) – classic framed look
Decorative trims available: Black, Storm Grey, White (interchangeable after installation)
Please contact us for any of the following optional extras:
- Reverse Door Hanging Kit;
- Warm Air Ducting Kit.
